Redis & Valkey Explained Visually: Cache-Aside, Write-Through, and Preventing Cache Stampedes

The Redis Licensing Schism and the Rise of Valkey

In-memory data stores form the backbone of modern web performance. For over fifteen years, Redis served as the undisputed standard for sub-millisecond caching, session state management, and pub/sub message brokers. However, the commercial licensing shifts of recent years prompted the open-source community—backed by the Linux Foundation, AWS, Google Cloud, and enterprise Linux distributions—to fork the codebase into Valkey.

Valkey preserves the open BSD-3-Clause license, maintains 100% wire-protocol compatibility with Redis 7.2 clients, and introduces performance optimizations in multi-threaded socket handling on Debian. Whether your cluster runs Redis or Valkey, treating the in-memory engine as a simplistic key-value bucket without architectural discipline leads directly to memory fragmentation, stale data corruption, and catastrophic database outages.

IN-MEMORY STORE EVOLUTION: REDIS TO VALKEY

• ORIGINAL OPEN-SOURCE REDIS (BSD-3-Clause)
• Commercial Redis (Dual Proprietary License SSPLv1/RSALv2)
• VALKEY (Linux Foundation Open Source Governance)
• 100% Drop-in Binary & Protocol Replacement
• Multi-threaded Event Loop Enhancements
• Native Support in Enterprise Linux Package Trees

At Webxtek, we engineer systems where in-memory caching acts as a predictable shock absorber. Pairing low-latency memory stores with our high-performance website platforms and scalable web application architectures ensures that high-volume platforms absorb viral traffic spikes with zero degradation.

Architectural Caching Patterns: Cache-Aside vs. Write-Through

The two dominant caching patterns reflect fundamentally different operational trade-offs regarding data freshness and latency.

1. The Cache-Aside (Lazy-Loading) Pattern

In Cache-Aside, the cache engine has no direct relationship with the database. The application layer orchestrates all interactions:

CACHE-ASIDE (LAZY-LOADING) REQUEST FLOW

1. Client Requests User Profile (ID: 481)

• 2. App Queries Valkey/Redis → Cache Hit? → Return Profile (0.4ms)
• (Cache Miss!)
• 3. App Queries PostgreSQL Database (12ms)

4. App Writes Result to Valkey with TTL (e.g., SET user: 481 … EX 3600)

• 5. Return Profile to Client

Advantages: Resilient to cache failure (a down cache simply degrades to database queries); memory is only consumed by requested items.
Disadvantages: Initial cache miss penalty; risk of serving stale data if database updates bypass cache invalidation.

2. The Write-Through Pattern

In Write-Through, the cache sits inline between the application and the persistent store. When data is modified, the application writes to the cache, which writes synchronously to PostgreSQL before confirming success.

WRITE-THROUGH SYNCHRONOUS MUTATION

• Application Mutation Request
• In-Memory Store: Valkey: (Atomic Write) → [ Persistent PostgreSQL DB ]
• Both Confirmed Success
• Return HTTP 200 OK to Client

The Thundering Herd: Cache Stampede Prevention

A cache stampede occurs when a heavily requested key expires. Consider a homepage catalog payload queried by 800 concurrent requests per second. The moment its TTL expires at 12:00:00, all 800 threads experience a cache miss simultaneously. Each thread attempts to compute the expensive database query, spiking CPU usage to 100% and crashing the database engine.

THE CATASTROPHIC CACHE STAMPEDE (THUNDERING HERD)

• Hot Key catalog:featured Expires at 12:00:00!
• Request 1 (Miss)
• Request 2 (Miss) → [ 800 Concurrent Database Queries! ]
• Request 3 (Miss) → [ PostgreSQL Connection Pool Exhausted ]
• Request 800 (Miss) → [ Web Server Drops HTTP 504 Timeouts ]

The Solution: Distributed Mutex Locking (SETNX)

To prevent stampedes, only the first thread that encounters a miss is permitted to query the database. All subsequent threads either wait or receive a slightly stale cached payload:

// Node.js implementation of distributed mutex lock with fallback
async function getCachedCatalog(redisClient, dbClient) {
  const cacheKey = "catalog:featured";
  let data = await redisClient.get(cacheKey);

  if (!data) {
    const lockKey = `lock:${cacheKey}`;
    // Acquire distributed lock for 5 seconds using atomic NX
    const acquired = await redisClient.set(lockKey, "locked", "NX", "EX", 5);

    if (acquired) {
      try {
        // Only one worker queries the database
        data = await dbClient.query("SELECT * FROM products WHERE featured = true");
        await redisClient.set(cacheKey, JSON.stringify(data), "EX", 300);
      } finally {
        await redisClient.del(lockKey);
      }
    } else {
      // Other workers sleep 50ms and retry or return stale fallback
      await new Promise((r) => setTimeout(r, 50));
      return getCachedCatalog(redisClient, dbClient);
    }
  }
  return JSON.parse(data);
}

Memory Eviction Policies: volatile-lru vs. allkeys-lru

When Valkey reaches its allocated memory limit (maxmemory), it must evict existing keys to accommodate new writes. Selecting the wrong policy will cause unpredictable data loss.

Configure /etc/valkey/valkey.conf:

# Cap memory allocation to 4 Gigabytes
maxmemory 4gb

# Choose eviction strategy carefully
maxmemory-policy volatile-lru

# Number of keys sampled for LRU approximation
maxmemory-samples 7

VALKEY MEMORY EVICTION POLICIES

• POLICY: volatile-lru
• Only evicts keys that have an explicit EXPIRE / TTL set.
• SAFEST for mixed instances containing sessions, queues, and caches.
• If no TTL keys remain, writes throw OOM errors rather than dropping data.
• POLICY: allkeys-lru
• Evicts ANY key based on least-recently-used heuristics.
• IDEAL for pure caching instances where every key can be recomputed.
• DANGEROUS if persistent background jobs or queues reside in the instance.

Production Deployment and Persistence Choices

Configuring Valkey for production requires choosing between Redis Database snapshots (RDB) and Append-Only Files (AOF). For pure caching tiers, disabling persistence entirely (save "" and appendonly no) yields the lowest latency and eliminates disk I/O bottlenecks.

For stateful sessions, configure hybrid persistence:

# Enable AOF with fsync every second
appendonly yes
appendfsync everysec
auto-aof-rewrite-percentage 100
auto-aof-rewrite-min-size 64mb

You can review production tuning scripts hosted on GitHub to integrate Valkey metrics into Prometheus.

Combining memory-tuned Valkey instances with our scalable managed hosting solutions ensures that your web applications deliver lightning-fast responses without sacrificing transactional data integrity.
